Artno: 547964

22 199 kr (inkl. mva)

Beskrivelse

Spesifikasjon

The L7 effectively maximizes sound pressure level thanks to high-performance loudspeakers, drivers and muscular 2000 watts Pascal Class-D amplifiers and delivers ultra-precise coverage of frequency spectrum thanks to minimized distortion and optimized directivity. Includes a state-of-the-art DSP platform with integrated fully parametric 10-band EQ, delay and limiting for uncompromised individual configuration that offers the latest networking technology to control Theo DSP of every LINEAR 7 cabinet from that one central FOH spot.

Additional DSP-Out that lets you integrate an added non-network-compatible powered cabinet (such as your LINEAR series active subwoofers) into the network and remotely control it with all the parameters of the LINEAR 7 DSP that´s easy to control with the direct access to easy selectable presets for use as full range cabinet or in a system, even in a non-network setup. The futureproof Audio-Streaming (Certification for MILAN is in the works) operates in high resolution 96 kHz AD/DA converters, FIR-filtering and low latency.

L7 provides a full range housing for maximum bass output and a user friendly rigging and mounting option.

• Peak Power: 2.000 watts

• Power Amp: Class-D, Bi-Amped

• Woofer: 12" (2" Voice Coil)

• Tweeter: 1" (1.75" Voice Coil)

• Horn: 70° x 50° CD, rotatable

• X-over: ca. 1.8 kHz, FIR

• Analog inputs : XLR / ¼“ Jack

• Analog Thru: XLR

• DSP Out: XLR

• Network connectors: 2x Ethercon

• DAN-Protocol (Audio-Streaming): Milan (Certification in progress)

• DSP-functions fully parametric 10-band EQ with variable filter-characteristics, high pass filter, low pass filter, polarity, level, delay, limiter

• Operating system for remote software: Windows, Mac OS (app for iPad will follow)

• Sampling-Rate: 96 kHz

• Latency: 2.6 ms

• Mains input: Powercon

• Power supply : automatic switching power supply (100 to 240 volts)

• Rigging points : 5 x M8 for use with AP-8 or tilt adapter

• Rigging frame : TB + TA-28N

• Setup angle: 33°

• Front grille: 2 mm powder coated metal grille, black acoustic foam

• Housing: 15 mm birch multiplex / MDF-hybrid

• Finish : Environment-friendly Warnex acrylic enamel

• Handles: 2x Bar-Handle

• Pole mount: Duo Tilt (3° / 7°)

• Dimensions: 37 x 67 x 30 cm

• Weight: ca. 21 kg
